Order number 8600260
Main features | |
|---|---|
Light source / lamps | 2x LED |
Mast | Stufenlos 360° drehbar |
Light flux (Lumens) approx. [lm] | 140.000 |
Dimensions L x W x H [mm] | 6365 x 1610 x 2527 |
Shockproof sockets | 1 x CEE 400V / 125A / IP67 / 1h 1 x CEE 400V / 63A / IP67 / 1h 1 x CEE 400V / 63A / IP67 1 x CEE 400V / 32A / IP67 2 x CEE 400V / 16A / IP67 3 x 230V / 16A / IP68 |
Chassis | |
Trailer drawbar | höhenverstellbar |
Main features | |
Continuous power (PRP) [kVA/kW] | 60.3/48.2 |
Alternator type | synchron |
Nominal voltage [V] | 400/230 |
Nominal current 3~ (PRP) [A] | 87,1 |
Frequency [Hz] | 50 |
Voltage regulation | elektronisch |
Engine | |
Brand | FPT |
Model | F34TEVP01 |
Cooling system | wassergekühlt |
Displacement [ccm] | 3400 |
Engine output (PRP) [kW] | 55 |
RPM [U/min] | 1500 |
RPM regulation | elektronisch |
Fuel | Diesel |
Fuel consumption @ 75% PRP [L/h] | 8,32 |
Running time @ 75% PRP | 25,1 |
Starting system | Elektrostart |
Electric circuit | 12 |
Sound power level LWA [db(A)] | 93 |
Sound pressure level LPA (7 m) [db(A)] | 68 |
- Generous, individually adjustable storage space concept with large volume
- Heavy-duty shelves for your loading
- Durable roller shutters mounted on both sides with rod lock
- Lockable control panel with lockable cable feed-through
- Including IT/TN operating changeover according to DIN/TS 14684
- High quality generator according to emission class EU Stage V
- Fully galvanised chassis according to StVZO with a height adjustable trailer drawbar
- Diesel filter with water trap
- Automatic control panel with digital control
- Splash-proof control cabinet
- Liquid collecting tray to protect the environment
- Leakage sensor
- Three-way fuel valve for external refuelling
- Integral battery charger incl. 230 V /16 A socket
- Main battery switch
- Oil drain pump
- Document bag
- Hot engine parts protection
- Insulation monitoring
- Voltage transformer
Dummy-Load | Article number: 342 500 |
Rear warning system | Article number: 342 501 |
Rear warning system removable | Article number: 342 513 |
Headlight package LLED 200.000 Lumen | Article number: 342 512 |
Ambient lighting, LED | Article number: 342 504 |
Engine bay lighting | Article number: 342 514 |
6 kg ABC fire extinguisher incl. Holder | Article number: 342 509 |
Fire extinguisher 5kg CO² incl. protection box | Article number: 342 508 |
Extension of the chassis approval from 80 km/h to 100km/h | Article number: 341 138 |
MELF Box charging receptacle 230V 16A | Article number: 162 297 |
MELF Box connecting cable | Article number: 162 296 |
Charging current socket Rettbox | Article number: 163 037 |
External start Nato socket | Article number: 162 056 |
Refuelling set, 2x 10m hose (supply + return) incl. conn. to the 3-way fuel valve | Article number: 162 052 |
Special colour | Article number: auf Anfrage |
