Order number 156322
Alternator type | Duplex |
Max. Output 1~ [kVA/kW] | 4.4/4.0 |
Continuous Power 3~ [kVA/kW] | 6.0/4.8 |
Continuous Power 1~ [kVA/kW] | 4.0/3.6 |
Nominal voltage [V] | 400/230 |
Nominal Current [A] | 8.7/17.4 |
Frequency [Hz] | 50 |
Engine | |
|---|---|
Engine Type | Hatz 1B 50 |
Design | 1-Zyl. 4-Takt OHV |
Displacement [ccm] | 517 |
Output 3000 rpm | 7,6 |
CO2 emissions [g / kWh] | 829,69 |
CO2 test procedure | NRSC-D2 |
Fuel | Diesel |
Fuel consumption @ 75% PRP [L/h] | 1,45 |
Running time @ 75% PRP | 5,5 |
Starting system | Elektrostart |
Weight in kg ca. | 154 |
Dimensions L x W x H [mm] | 700 x 440 x 580 |
Shockproof sockets | 3 × 230 V / 16 A 1 × CEE 400 V / 16 A |
- Fitted according to DIN 14685-1
- Comprehensive functions, safe and simple operation
- DUPLEX current quality without compromise
- Multifunctional control display E-MCS 4.0 - a clear system
- Large fuel tank for long operation – without refuelling
- Emergency start function over the recoil starter
- Special equipment and accessories, available for many requirements
- Insulation monitoring – without shut-off
- Connection for external fuelling
- Multifunction control display E-MCS 4.0
- Fuel level indicator over the E-MCS 4.0
- Lack of oil automatic switch-off
- Alternator overload protection
- Starter battery 12 V/20 A
- Folding handles
- Spark plug wrench
Remote start device | Article number: 163 150 |
Supplying power to a building IT/TN | Article number: 162 050 |
Beos charging current socket | Article number: 163 080 |
Charging current socket DIN 14690 | Article number: 163 010 |
Charging current socket MagCode | Article number: 163 018 |
Insulation monitoring device with shut-off | Article number: 163 071 |
Colour red RAL 3000 | Article number: 163 180 |
