Technical data and documentation
ESE 25 BW

Order number 320403

Main features

Prime power (PRP) [kVA/kW]

20.0/16.0

Alternator type

ECP28 M4C

Nominal voltage [V]

400/230

Nominal current 3~ (PRP) [A]

28,9

Frequency [Hz]

50

Voltage regulation

electrical

Weight in kg ca.

650

Dimensions L x W x H [mm]

1825 x 950 x 1118

Engine

Brand

Baudouin

Model

4M08G4D3-5

Emission regulation

Stage 3A

Cooling system

wassergekühlt

Displacement [ccm]

3170

Engine output (PRP) [kW]

25

RPM [U/min]

1500

RPM regulation

elektronisch

Fuel

Diesel

Fuel tank capacity [l]

70

Fuel consumption @ 75% PRP [L/h]

4,93

Running time @ 75% PRP

13,2

Starting system

Elektrostart

Electric circuit

12

  • 3-phase sensing AVR
  • Problem-free use, also in winter through use of a standard engine and coolant prewarming
  • Diesel filter with water trap

Terminal board

Article number: auf Anfrage
