Order number 335277
Main features | |
|---|---|
Prime power (PRP) [kVA/kW] | 94/75,2 |
Nominal voltage [V] | 400/230 |
Nominal current 3~ (PRP) [A] | 135,8 |
Frequency [Hz] | 50 |
Voltage regulation | elektronisch |
Weight in kg ca. | 2130 |
Dimensions L x W x H [mm] | 3440 x 1195 x 1961 |
Engine | |
Brand | FPT |
Model | F36ETVP03.A94 |
Emission regulation | Stage V |
Cooling system | wassergekühlt |
Displacement [ccm] | 3600 |
Engine output (PRP) [kW] | 85,5 |
RPM [U/min] | 1500 |
RPM regulation | elektronisch |
Fuel | Diesel |
Fuel tank capacity [l] | 420 |
Fuel consumption @ 75% PRP [L/h] | 15,5 |
Running time @ 75% PRP | 27,1 |
Starting system | Elektrostart |
Electric circuit | 12 |
Sound power level LWA [db(A)] | 97 |
Sound pressure level LPA (7 m) [db(A)] | 72 |
Shockproof sockets | 1x CEE 400V / 63A 1x CEE 400V / 32A 1x CEE 400V / 16A 1x CEE 230V / 16A 1x 230V / 16A Schuko |
- Soundproofed hood - extra quiet
- Engine according to Emissions Stage V
- Manual/Automatic instrument panel in IP 54
- Base frame with continuous fork-lift plates and ram protection
- Galvanised hood for increased corrosion protection
- Large tank for long running times
- Liquid collecting tray to protect the environment
- Prepared for coolant pre-heating as standard
- Main battery switch
- Manual oil scavenger pump
- Remote start connection
- Diesel filter with water trap
- Connection for a 230 V / 16 A battery charge
- Hot engine parts protection
- Document bag
Socket combination 2 with RCD Type B (incl. terminal board) | Article number: 342 725 |
Socket combination 3 with RCD Type B (terminal board will be removed / incl. Insulation monitoring) | Article number: 342 036 |
Insulation monitoring | Article number: 163 076 |
Powerlock connector | Article number: 342 034 |
E-RMA SIM remote monitoring | Article number: 342 220 |
E-RMA LAN remote monitoring | Article number: 342 221 |
Special colour | Article number: auf Anfrage |
