Order number 355220
Main features | |
|---|---|
Prime power (PRP) [kVA/kW] | 18,3/14,6 |
Alternator type | ECP28 M4 C |
Nominal voltage [V] | 400/230 |
Nominal current 3~ (PRP) [A] | 26 |
Frequency [Hz] | 50 |
Weight in kg ca. | 705 |
Dimensions L x W x H [mm] | 2200 x 1020 x 1313 |
Engine | |
Brand | YANMAR |
Model | 4TNV88-BIPGE |
Emission regulation | Stage V |
Cooling system | wassergekühlt |
Displacement [ccm] | 2190 |
Engine output (PRP) [kW] | 17,3 |
RPM [U/min] | 1500 |
RPM regulation | mechanisch |
Fuel | Diesel |
Fuel tank capacity [l] | 80 |
Fuel consumption @ 75% PRP [L/h] | 3,69 |
Running time @ 75% PRP | 21,7 |
Starting system | Elektrostart |
Electric circuit | 12 |
Sound power level LWA [db(A)] | 92 |
Sound pressure level LPA (7 m) [db(A)] | 67 |
- Automatic control panel with digital control
- Diesel filter with water trap
- Main battery switch
- Hot engine parts protection
- Manual oil scavenger pump
- Liquid collecting tray to protect the environment
Socket combination 1 with RCD Type A (incl. terminal board) | Article number: auf Anfrage |
Insulation monitoring | Article number: 163 076 |
E-RMA SIM remote monitoring | Article number: 342 228 |
E-RMA LAN remote monitoring | Article number: 342 229 |
ENDRESS Elektrogerätebau GmbH
Neckartenzlinger Straße 39
D-72658 Bempflingen
Tel.: +49 (0) 71 23 / 97 37 - 0
E-Mail: info@endress-stromerzeuger.de
